FH55T
Safety Relays
Feature Description
● 8A switching capability
● Contact arrangement::2C?AB1?AB2
● Contact structure of mandatory oriented:EN50205 compliant
● UL insulation system:Class B?Class F
● Strong insulation ability:Surge voltage (Between coil&contacts) :10KV Surge voltage(Between contact groups) (Waveform 1.2/50μs):6kV
● Environmental friendly product(RoHS compliant)
Product Description
Download PDF
