W16
Power Relay
Feature Description
● 10A switching capability
● Contact arrangement:1A?1C
● Products with operating temperature of 105℃ are available
● Provide high sensitive type,coil power is :200mW
● UL insulation system:Class F
● Environment-friendly product(RoHS compliant)
● Outline Dimensions:(20.5×10.5×15.6)mm
● Main application:Home appliance?Electric power meter
Product Description
