Feature Description

● 43A switching capability
● 1A contact form
● Provide the contact gap of the product is≥2.0mm,conforming to IEC62109-2-2011
● Save the power consumption of the whole machine, and keep working by reducing the coil voltage after starting
● UL insulation system:Class F
● Environment-friendly product(RoHS compliant)
● Outline Dimensions:(30.3×15.4×23.1)mm
● Main application:New energy and PV industry?Charging Piles
